Brand:
SKYJACK
|
|
Working height:
25' | 7,62 m
|
|
Platform height, lowered:
0,99 m | 3,25'
|
|
Overall Width:
0,81 m | 2,66'
|
|
Platform width (inside dimension):
0,66 m | 2,17'
|
|
Platform length (inside dimension):
1,63 m | 5,35'
|
|
Gradeability:
30%
|
|
Capacity:
249 kg | 550 lb
|
|
Tire type:
Solid, N/M
|
|
Tire size:
12 x 4 x 8"
|
|
Local ground load (with rated load):
759 kPa (110 lb/po²)
|
|
Type of energy:
Electric
|
|
Weight:
1 170 kg (2 580 lb)
|
|
Turning radius - outside:
1,68 m | 5,51'
|
|
Max. wind speed:
12,5 m/s (28 mi/h)
|
|
Wheelbase:
1,40 m | 4,59'
|
|
Overall length:
1,78 m | 5,84'
|
|
Ground clearance (stowed):
6,03 cm (2,37")
|
|
Ground clearance (platform raised):
1,78 cm (0,7")
|
|
Overall floor load (with rated load):
10 kPa (201 lb/pi²)
|
|
Lifting time (with rated load):
25 s
|
|
Lowering time (with rated load):
29 s
|
|
Driving speed (in stowed position):
3,2 km/h (2 mi/h)
|
|
Driving speed (platform lifted):
1,1 km/h (0,7 mi/h)
|
|
Maximum drive height:
Hauteur totale
|
|
Maximum number of persons:
2
|
|
Platform height lifted:
19' | 5,79 m
|
|
Stowed height (railings mounted):
1,99 m | 6,53'
|
|
Stowed Height (Guardrails Down):
1,64 m | 5,38'
|
|
Platform extension (sliding):
3' | 0,91 m
|
|
Distributed Capacity (Primary Platform):
136 kg | 300 lb
|
|
Distributed capacity (platform extension):
113 kg | 250 lb
|
